Name: 220-240V 50Hz 55W 820RPM zewnętrzny wentylator silnik do klimatyzacji
Brand: Changzhou Trustec Company Limited
SKU: YDK-55-6A8-SGR
Price: 125.00 USD
Availability: InStock

Dom Produkty Na zewnątrz silnika wentylatora

220-240V 50Hz 55W 820RPM zewnętrzny wentylator silnik do klimatyzacji

220-240V 50Hz 55W 820RPM Outdoor Fan Motor for Air Conditioning

Szczegóły Produktu:

Place of Origin:	Changzhou, China
Nazwa handlowa:	trusTec
Orzecznictwo:	CE
Model Number:	YDK-55-6A8-SGR

Zapłata:

Minimum Order Quantity:	200 pcs
Cena:	Negotiable (FOB/CNF/CIF)
Packaging Details:	Standard carton packing, foam board inside for protection.
Delivery Time:	15 days fresh products after order confirmation.
Payment Terms:	T/T, L/C
Supply Ability:	100,000 pcs per month

Kontakt

Szczegółowy opis produktu

Product:	Outdoor Fan Motor	Frame Size:	95mm
Motor Type:	Permanent Split Capacitor	Supply Voltage:	220-240V
Enclosure Type:	TEAO(Totally Enclosed Air Over)	Supply Frequency:	50Hz
Thermal Overload:	Equipped with an Automatic Thermal Overload	Current:	0.5A
Phase:	Single Phase	Output HP:	55W
Shaft Flats:	One flat	Rated Speed:	820±20RPM
Bearings:	Ball Bearing	Pole:	6P
Mounting:	Stud Mounting All Angel	Capacitor:	3.0MFD/450V
Insulation Class:	Class B	Shaft Diameter:	0.47" /12mm
Rotation:	CCW-SE	Shaft Length:	3.48" /88.5mm
Max. Ambient Temperature:	40℃/104℉	Flat Length:	0.63" /16mm
PF:	0.9	Lead Length:	43.3" /1100mm
Housing Length:	3.58" /91mm
Podkreślić:	55W zewnętrzny silnik wentylatora , Silnik wentylatora zewnętrznego 820 obr./min
